POLYETHYLENE TUBING (PE)
PE Tubing is widely used in industrial, chemical and perhaps most commonly for the transfer of air, water and other foodstuffs.
Our PE tubing is sourced from UK and well know European & International manufacturers and is available in coils and drum quantities at most sizes. It comes in a number of variants from LDPE, PE and even an advanced PE each with their own properties.
Some examples of the types of approvals that the tubing may have are FDA, NSF, Wras, DI & Reach.
Features & Benefits
- Suitable for food use
- Durable
- Flexible
- Lightweight
- Chemically inert
- Plasticiser free
- Does not impart taste or odour to contents
Applications
- Chemical lines
- Food and beverage lines
- Paint spray
- Solvent lines
- Low pressure pneumatic lines
- Instrumentation
- Laboratory uses
Chemical Resistance
PE tubing has an excellent resistance to a range of chemicals ensuring its suitability for the conveyance of many substances. It is resistant to most:
- Solvents
- Alkalis
- Oils
- Greases
- Petroleum products
- Fungi
- Moulds
- Dilute acids (mineral and organic)
Working Temperature range example : -40C to 95C
| Range | Description | Size | Carrier - Min Burst Pressure | Bend Radius |
|---|---|---|---|---|
| TUBE | PE - 2.5 | 2.5 x 4 mm | 696 PSI / 48 bar | 16 mm |
| TUBE | PE - 4 | 4 x 6 mm | 696 PSI / 48 bar | 32 mm |
| TUBE | PE - 5.75 | 5.75 x 8 mm | 565 PSI / 39 bar | 40 mm |
| TUBE | PE - 7 | 7 x 10 mm | 565 PSI / 39 bar | 40 mm |
| TUBE | PE - 9 | 9 x 12 mm | 478 PSI / 33 bar | 55 mm |
** all data is for illustration only based on manufacturers data which is subject to their tolerances and change without notice
pressures stated at 20c
